KY-15T/G1000 - Dispositivo de proteção contra surtos de corrente contínua T1+T2 (1000V)
(1) The 1000v dc spd t1+t2 KY-15T/G1000 provides combined Type 1+2 surge protection for photovoltaic systems.
(2) Designed for PV combiner boxes, inverters, and DC feeders, compliant with IEC 61643-31 and CE/UKCA/RoHS standards.
(3) Includes remote alarm contact option, replaceable module design, and shared wiring/dimension diagrams for T1+T2 series.
Visão geral
O 1000v dc spd t1+t2 KY-15T/G1000 is a surge protective device engineered for
Caixas combinadoras fotovoltaicas, DC feeders, and inverter DC inputs up to 1000VDC.
It provides coordinated Type 1+2 protection against lightning currents and switching surges,
reducing residual voltage to safeguard sensitive PV equipment.
Fully compliant with IEC 61643-31 and certified CE, UKCA, and RoHS.
Principais recursos
- Combined 1000v dc spd t1+t2 protection for photovoltaic DC circuits.
- Clear status indicator and replaceable cartridge for easy maintenance.
- Remote alarm contact terminals reserved (per datasheet specifications).
- Compact, flame-retardant enclosure (UL94-V0) with 35mm DIN-rail mounting.
- Coordinates with fusíveis gPV e
Seccionadores de chave CC in a
complete surge protection system.
Especificações
| Tipo | T1+T2 |
|---|---|
| System Voltage (Ucpv) | 1000 V CC |
| Nominal Discharge Current (In) | 20 kA |
| Maximum Discharge Current (Imax) | 40 kA |
| Impulse Current (Iimp) | 6.25 kA |
| Voltage Protection Level (Up) | ≤ 3.5 kV |
| Response Time (ta) | < 25 ns |
| Admissible Short-Circuit Current (Iscpv) | 10 kA |
| Remote Alarm Contact | 220V, 0.5A, NO/NC |
| Padrões | IEC 61643-31, GB/T 18802.31, CE, UKCA, RoHS |
Wiring & Dimension
Fiação:
Dimension:
Aplicativos
- PV combiner boxes and inverter DC terminals requiring T1+T2 SPD protection.
- Main DC feeders in utility-scale and ground-mount solar plants.
- Commercial and industrial rooftop solar PV systems with high surge exposure.
FAQs
Q1. What is the difference between a 1000v dc spd t1+t2 and a type 2 only SPD?
The KY-15T/G1000 combines Type 1 lightning current capability with Type 2 low residual voltage protection,
while Type 2 alone cannot handle direct lightning currents.
Q2. Can the 1000v dc spd t1+t2 be used in residential PV combiner boxes?
Yes, it is suitable for residential and commercial PV combiner boxes operating at 1000V DC.
Q3. Does KY-15T/G1000 include remote alarm contacts?
Yes, alarm terminals (NO/NC) are reserved and rated 220V, 0.5A as specified in the datasheet.
Q4. Which standards does the KY-15T/G1000 comply with?
IEC 61643-31, GB/T 18802.31, CE, UKCA, and RoHS certifications are covered.
